Hi all, I mounted some snow tires this week and want to pass along some information that might be useful. I was able to re-use an extra set of 17" wheels we had for our 2012 Focus Titanium. Note that other Focus models came standard with 16", or could be ordered with 18" optional wheels, so if you go this route, be sure of what size you are planning to use or get. I believe some Escape wheels are also the same size as Focus, but please do your homework to confirm rather than take my word for it. .

The Focus wheels I have are the same size as our 2022 Badlands wheels (17x7), same 5x108 lug pattern, and have the same hub bore. The offset is different - Badlands wheels are marked (-)37.6mm while the Focus wheels are (-)50mm. This means an additional -12.4mm offset (slightly less than 1/2"), which tucks the wheels a bit further inside the wheel wells. In my mind this is not a bad thing for winter tires, by helping keep sand and rock chips at bay.

I am running 235/65-17 Nokain Hakkapellitta studded tires and do not have any clearance or rubbing problems. However the inside forward edge of the driver's side front tire gets close (less than 1/2") from rubbing the fender liner at full turn. There is a slight bulge in the fender liner at that location so if you plan to run 245's or larger on Focus (or other, i.e. Escape, etc.) wheels with -50mm offset, they may rub slightly. Based on this, I also doubt that optional 18x8 versions would work if they are the same -50mm offset.

Also, thanks to @wilbur_xmas who mentioned it in their post, I can confirm that the TPMS sensors ordered from Tire Rack work without additional programming. The sensors I received are part number S163, which are Schrader #20452, and were $27/each when I ordered. I went this route as the local tire shop wanted $60/each for their programmable sensors.


Focus on left, Badlands on right.
Fitments below:




Badlands offset:


Focus offset:




Hopefully this is helpful for those looking for an extra set of wheels for winter use, or whatever other use you have in mind. While I would've preferred a set of the optional BL 'Steelies', but these look good and saved us the additional time and cost of finding another set. It may be a while before BS sets are readily available at a reasonable cost.
Advertisement



Escape2Bronco

Badlands
Well-Known Member
First Name
Steve
Joined
Oct 9, 2021
Messages
119
Reaction score
102
Location
USA
Vehicle(s)
Ford Escape
Looks great plus studs! Boy, I really miss those. I just wrecked my wife’s HRV going around a corner and hit black ice. Did 3.5k worth of damage to the suspension. Only thing that would have helped would have been studded tires but they have been outlawed here for 50 years or so.


AndyMac204

Base
Well-Known Member
First Name
Andy
Joined
Jun 27, 2021
Messages
383
Reaction score
516
Location
Canada
Vehicle(s)
2021 Bronco Sport Base / 1988 Dodge Power Ram w150
i think it looks awesome tbh. thanks for sharing.


Osco

Base
Well-Known Member
First Name
Marty
Joined
Dec 19, 2020
Messages
947
Reaction score
1,600
Location
North Carolina
Vehicle(s)
2021 Ford Bronco Sport and 2004 Ford Escape AWD
Dumb ?,
Why didn’t you take the TP sensors off your Badlands wheels and use them ?

OP
OP
MaxVelocity

MaxVelocity

Badlands
Well-Known Member
Joined
Sep 20, 2021
Messages
190
Reaction score
221
Location
Montana
Vehicle(s)
1970 Bronco
Dumb ?,
Why didn’t you take the TP sensors off your Badlands wheels and use them ?
Because my BL wheels still have the AT tires mounted for summer use.


Area51

Badlands
Member
First Name
Tom
Joined
Nov 21, 2020
Messages
6
Reaction score
4
Location
North Dakota
Vehicle(s)
’21 Badlands, ’08 Ranger 4x4, ’16 Focus ST
What a great idea.
